T5+ 5.5inch 1000nits 4K HDMI On-camera Monitor Kit
I realised a video review of the monitor: https://youtu.be/5OT4r-GoaTc
I bought it about 2 weeks ago, the shipping was fast and the monitor is just awesome. I am very happy with it. I am thinking about the G7 which has SDI inputs as well as HDMI.
Thank you Osee
I love the feature set of this monitor - I’m coming from a more expensive touchscreen monitor, but got tired of some of its quirks while working in the field. I saw some good reviews of this one, and decided to give it a go - I really love the joystick, being able to quickly zoom in, adjust brightness, and swipe between tool sets, all without touching the screen or constantly going into menus. The screen itself is very clear and bright enough for most outdoor work. The recessed HDMI is a nice touch.
The negative? Mine started developing problems after a few days of use - there’s a high-pitched squeal that comes from the monitor that wasn’t there when I first got it, and it resets all my settings whenever I change the battery or unhook the power. Very frustrating.
I’ve sent support an email, but I’m still waiting for a reply - hopefully, this review gets their attention. I hope I can get it resolved because it’s otherwise a great monitor to work with!
very satisfied
Bright
T5+ is the new upgraded version of osee's most popular model T5 with a brand new daylight viewable 1000nits panel. Making it suitable for both studio and outdoor videography.
What's more, with a contrast ratio of 1000:1 and osee's LOG/HDR processing technology, HDR realtime monitoring is not a problem anymore. Users can shoot HDR format and the monitor will help transform it into a standard image to monitor right in the field.
*Please confirm your LOG/HDR settings before shooting videos (refer to QSG page 6, Video Assist Features >> LOG/HDR Workflow).
Light
This monitor only weighs 175g without battery and has a size similar with your phone. With a plastic ABS polycarbonate shell and a built-in aluminum sheet, it is not only light but also quite sturdy as well. It also has two metal 1/4'' metal screw holes with anti-rotation pin holes, you can attach it on your camera, gimbal, cage... You can fit it into all kinds of setups without loose.
Smart
T5+ features the first generation of osee's MON OS, a convenient page style user interface that allows you to add up to 8 MySets, and up to 8 different image assist tools can be added in each MySet. When monitoring on location, users can switch between MySets to check different things at ease with simple toggles.
Osee's MON OS has a full package of upgraded video assisting tools which you can check in the Tech Specs tab.
* Factory has 3 MySets (frame, exposure, focus) preset, you can edit them to your preferences.
What's in the Box
The Standard Package Includes:
T5+ Monitor
Tilt Arm
Sun Hood
HDMI-Micro Cable(30cm), HDMI-mini Cable(30cm)

Tech Specs
Hardware | |
---|---|
Display | |
Panel Size | 5.5inch |
Aspect Ratio | 16:9 |
Resolution | 1920x1080 |
PPI | 400 |
Brightness | 1000nits |
Contrast | 1000:1 |
Color Depth | 1.06G |
Backlight | Edge lit |
Viewing Angle | 160x160 |
Environmental | |
Body | Polycarbonate ABS plastic (with aluminum sheet built-in) |
Weight | 175g |
Dimensions | 157.5mmx79mmx20mm |
Mounting Points | 1/4”-20 anti-rotation screw mount, 1x bottom and 1x right |
Operating Temp | 0-40℃ |
Power | |
Battery Type | Sony NP-F/Canon LP-E6 |
Battery In | 5-17V |
Type-C In | 5-17V |
Battery Out | 5-8.4V |
Consumption | 5.5W |
Data I/O | |
Signal Input | HDMI 1.4 |
Signal Format |
3840x2160p(30/29.97/25/24/23.98) 1080p(60/59.94/50/30/29.97/25/24/23.98) 1080i(60/59.94/50) 720p(60/59.94/50) 480i/576i/480p/576p |
SD Card Slot | User LUT Upload&Firmware Upgrade (FAT32 format and under 16G size recommended) |
Audio Jack | 3.5mm |
Remote Jack | 2.5mm |
Software | |
Control | |
Backlight | Level 1-10 |
Volume | Level 0-31 |
Rotate/Mirror | Rotate (0, 180, auto), Mirror |
Probe Location | Set this to let exposure tools analyze before or after User LUT |
Frame Tools | |
Aspect | 9:16 (Phone), 4:5, 1:1, 4:3 (SD TV), 1.375:1 (Cinema), 16:9 (HD TV), 1.85:1 (Cinema), 2.37:1 (Cinema), custom(1:3 - 3:1) |
Safe | Action&Title |
Center | Cross/Hollow |
Crosshatch | 2x2, 3x3 ... 9x9 |
Anamorphic | 1.33X, 1.4X, 1.5X, 1.6X, 1.8X, 1.9X, 2X with magnify function |
Exposure Tools | |
False Color | Spectrum/Follow camera/Custom |
Zebra | Custom tone 1 and tone 2 |
Waveform | Luma/RGB/Parade style, location, opacity&density adjustable |
Histogram | Luma/RGB style, location, opacity&density adjustable |
Vector Scope | Location, opacity&gain adjustable |
Focus Tools | |
Focus Assist | White, Red, Green, Blue,B&W background available |
Peaking | Intensity 1-10 |
Look Tools | |
De-log | HLG, PQ, Arri, BMD, Canon, Fuji, JVC, Nikon, Panasonic, RED, Sony |
User LUT | Up to 10 user LUTs can be uploaded, support LUT intensity adjustment |
Audio Tools | |
Audio Meter | Location&opacity adjustable |
Analysis Tools | |
Multi-scopes | Waveform, histogram, vector scope and audio meter around scaled image |
